BUNDLE: PENTAS HDR 1717 DR System with High Frequency X-Ray Machine
Sale
,

BUNDLE: PENTAS HDR 1717 DR System with High Frequency X-Ray Machine

Tags: , , ,

$47,950.00

Deposit will put system on HOLD for 3 days. Please contact us for financing options or to pay balance by other means.

Computer

Product price: $47,950.00
Total options:
Order total:
FacebookTwitterGoogle PlusPinterestLinkedin

Description

PENTAS 1717 Digital Radiography System

paired with

Del-UMG 400mA High Frequency X-ray generator

The rising star in veterinary digital radiography

PENTAS 1717 DR Systems include:

  • HDR Detector Panels – Highest Dynamic range available in the world
  • 5 year hardware warranty on every system*
  • Outperforming the competition in Image Quality, Price and Performance
  • American Made
  •  Premium High Definition 1717 Csi tethered Detector Panel
  • 23″ All in One Computer
  • Vizion™ Acquisition and viewing software
  • One Year GOLD Level Warranty and Support/5 Year Hardware coverage*

DEL-UMG 30kW, 400mA, High Frequency Generator

  • Item Features:
    – 125kVp
    – LCD display provides two and three-point operation for individual control of exposure parameters
    – Integrated 24 volt AC/DC power supply

Additional information

Computer

All in One 23" Computer
Brand

VUE Imaging
Connection

Cabled
Panel Size

17 x 17
Condition Rating

NEW
Gadox/CSi

CSi
Pixel Pitch

154 micron
Shades of Gray

16-bit
Software

Metron
Spacial Resolution (lp/mm)

3.3 lp/mm

System Details

Premium HDR 1717 Csi Panel – tethered 17″ x 17″ Cassette sized panel

Lower Noise. Lower Radiation. Clearer Images.

Cassette sized and easy to use, this low power consumption, thermal-efficient design panel has a single-cable connection for easy installation and operation. Image excellence at low dose, combined with Full Field Automatic Exposure Detection.

Vizion DR – Image Acquisition and Display software

Acquisition Software with Pre-Set Filters, Viewing Software with Calibration Tools

  • Store images by Owner, Animal, Date
  • Image calibration and magnification corrected measurement tools
  • Data basing: multiple DBs, share a common DB, merge/copy DBs
  • World class All Species Image Algorithms and High Frequency filtering technology (MEGA)
  • Archival Functions: CD burning; Configurable for Internet based Off-site Archival service
  • DICOM 3.0 Conformance and file I/O
  • Able to write DICOM compliant CD
  • Ability to write “Viewer Export CD/DVD”
  • Includes 1 copy of Software

Choice of Computer:

All-in-One 23″ Computer – TOUCH: Navigate between applications with the intuitive touch of a finger on this 23 IN WLED Full-HD Touch Display.

2-in-1 PC 17″ Convertible Laptop – The first of its size, the powerful 17″ 2-in-1 defines upscale, with vast HD screen space, discrete graphics capability and a brushed aluminum design.

DEL-UMG 400mA High Frequency X-ray Generator

Universal Anthem 30kW, 400mA, High Frequency Generator
Item Features:

  • 125kVp
  • LCD display provides two and three-point operation for individual control of exposure parameters
  • Integrated 24 volt AC/DC power supply
  • Integrated line match transformer
  • Continuous kV and mA stabilization
  • Automatic line voltage compensation
  • Tube protection software and circuitry
  • Adjustable wall mount bracket
  • 208v to 240v Range
  • Welded construction table with urine trap
  • Variable SID
  • Integrated tube stand travels full length of table
  • Angulating tube arm, angulation dial and operator handle
  • Articulating arm for generator console mounted on tube stand
  • Bilateral tube stand handles for passive movement
  • Foot activated “quiet” release electric table top locks, located at the table front and both table ends
  • HT Cable concealment
  • Foot activated exposure switch
  • Onsite installation

Warranty and Support

All new Digital Radiography systems come standard with 1 year Gold level hardware and Software support coverage. Vue Imaging warrants to the original purchaser that each new Digital Radiography Imaging System is free from defects in workmanship and materials for 12 months from date of sale to the end-user, and annually thereafter as purchased.

See purchase contract for amount and type of coverage included in original purchase price.

*All Vue Pentas digital radiography systems come with a 5 year Limited Hardware warranty. One year of VUE’s software support program is also included.

*Hardware warranty claims require that the DR system is currently enrolled in VUE’s Software Support Program.

Please contact a Vue consultant for a custom quote on additional support contracts and cloud archival.
